Specifications in detail

Image Sensor

• Type
  35.9 x 23.9 mm CMOS
• Effective Pixels
  Approx. 32.5 megapixels
• Total Pixels
  Approx. 34.2 megapixels
• Aspect Ratio
  3:2
• Low-Pass Filter
  Built-in/Fixed
• Sensor Cleaning
  EOS integrated cleaning system
• Colour Filter Type
  RGB Primary Colour
• Sensor Shift-IS
  Yes, up to 7.5-stops advantage at the center and 7.0-stops peripheral depending on the lens used¹

Image Processor

• Type
  DIGIC X

Lens

• Lens Mount
  RF / RF-S
  EF and EF-S lenses can be attached using: Mount Adapter EF-EOS R Control Ring Mount Adapter EF-EOS R, Drop-In Filter Mount Adapter EF-EOS R
  EF-M lenses are not compatible
• Focal Length
  Equivalent to 1.0x the focal length of the lens with RF and EF lenses, 1.6x with EF-S and RF-S lenses.
• Image Stabilisation
  Coordinated control OIS X IBIS / Digital

Focusing

• Type
  Dual Pixel CMOS AF II
• AF System / Points
  100% horizontal and 100% vertical with Whole Area AF or Subject detection selected²
• AF Working Range
  EV -6.5 – 21³
• AF Modes
  One Shot, Servo AF, AI Focus AF
• AF Methods
  Automatic selection: 1053 Available AF areas when automatically selected,
• AF Point Selection
  Manual selection: Spot AF
  Manual selection: 1-point AF (AF frame size can be changed) 6097 (stills)/ (4641) movie AF positions available
  Manual selection: AF point Expansion 4 points (up, down, left, right)
  Manual selection: AF point Expansion surrounding
  Manual selection: Flexible Zone AF 1-3 (all AF points divided into minimum 9 to 999 maximum focusing zones, where the width and height is also adjustable)
  Manual selection: Whole area AF
  Manual selection: Spot AF (Whole area tracking servo AF OFF)
  Manual selection: 1-point AF (Whole area tracking servo AF OFF)
  Manual selection: AF point Expansion 4 points (up, down, left, right) (Whole area tracking servo AF OFF)
  Manual selection: AF point Expansion surrounding (Whole area tracking servo AF OFF)
• AF Tracking
  Humans (Eyes, Face, Head, Body), Animals (Dogs, Cats, Birds and Horses) or Vehicles (Racing cars or Motor bikes, Airplanes and Trains), Register People Priority⁴ (up to 10 registered people)
• AF Lock
  Locked when shutter button is pressed halfway or AF ON is pressed in One Shot AF mode. Using customised button set to AF stop in AI servo
• AF Assist Beam
  Emitted by built in LED or optional dedicated Speedlite (flash)
• Manual Focus
  Selected on lens
• Focus Bracketing
  Yes with In-camera depth compositing supported in JPEG, HEIF, RAW, or C-RAW formats
• AF Microadjustment
  Not supported

Exposure Control

• Metering Modes
  Real-time with image sensor, 384-zone metering.
  (1) Evaluative metering (linked to All AF points)
  (2) Partial metering (Approx. 6.2% of screen at centre)
  (3) Spot metering: Centre spot metering (Approx. 2.9% screen at centre) AF point-linked spot metering not provided
  (4) Centre weighted average metering
• Metering Brightness Range
  EV -3 – 20 (at 23°C, ISO100, with evaluative metering)
• AE Lock
  Auto: AE lock takes effect when focus is achieved Manual: By AE lock button in P, Av, Fv, Tv and M modes
• Exposure Compensation
  +/-3 EV in 1/3 or 1/2 stop increments (can be combined with AEB)
• AEB
  +/-3 EV in 1/3 or 1/2 stop increments
• Anti-flicker Shooting
  Not supported
• ISO Sensitivity⁵
  Auto 100-64000 (in 1/3-stop or 1 stop increments)
  ISO can be expanded to L:50, H:102400⁶

Shutter

• Type
  Electronic shutter function on sensor
• Electronic Shutter Type
  Rolling Shutter
• Speed
  Electronic shutter: 30-1/16000 sec (1/2 or 1/3 stop increments)
  Mechanical / Electronic 1st Curtain shutter: 30-1/8000 sec (1/2 or 1/3 stop increments), Bulb
  (Total shutter speed range. Available range varies by shooting mode)
• Shutter Release
  Soft touch electromagnetic release

White Balance

• Type
  AWB (Ambience priority/White priority)- Shockless WB in movie recording, Daylight, Shade, Cloudy, Tungsten light, White Fluorescent light, Flash, Custom, Colour Temperature Setting
• Settings
  Custom white balance, White balance shift, White balance bracketing, Shockless WB, AWB response, AWB lock
• Shift
  White balance compensation:
  1. Blue/Amber ±9
  2. Magenta/Green ±9
• Custom White Balance
  Yes
• WB Bracketing
  ±3 levels in single level increments 3, 2, 5 or 7 bracketed images per shutter release
  Selectable Blue/Amber bias or Magenta/Green bias

Viewfinder

• Type
  Not provided

LCD Monitor

• Type
  7.5cm (3″) TFT Colour LCD, approx. 1.62 million dots
• Coverage
  Approx. 100%
• Viewing Angle (Horizontally/Vertically)
  Approx. 170° vertically and horizontally
• Coating
  Anti-smudge coating provided.
• Brightness Adjustment
  Auto, Manual: Adjustable to one of seven levels / Colour Tone Adjustment: 4 settings
• Touch Screen Operations
  Capacitive method with menu functions, Quick Control settings, playback operations, and magnified display. AF point selection in still and Movies, touch shutter is possible in still photo shooting.
• Display Options
  (1) Basic Camera settings
  (2) Advance Camera settings
  (3) Camera settings plus histogram and dual level display
  (4) No info
  (5) Quick Control Screen

Flash

• Built-in Flash GN (ISO 100, meters)
  Not provided
• Flash Red-Eye Reduction
  Not supported
• Multi-Function Shoe / HotShoe / PC Terminal
  Yes/No
• External Flash Compatibility
  Not supported

Shooting

• Modes
  Stills: Scene Intelligent Auto, Scene Mode (Portrait, Smooth Skin, Panoramic shot, Food, Handheld night scene), Flexible priority AE, Program AE, Shutter priority AE, Aperture priority AE, Manual, and Custom (x3)
  Movie: Scene Intelligent Auto, Movie for Close-Up Demos, Scene Mode (Smooth skin movie, Movie IS mode, HDR movies), Auto Exposure, Shutter priority AE, Aperture priority AE, Manual, S&F (S&F Auto, S&F Shutter-priority AE, S&F aperture-priority AE, S&F manual), and Custom (x3)
• Special Scene Modes
  Still: Portrait, Smooth Skin, Panoramic shot, Food, Handheld Night Scene
  Movie: Smooth skin, Movie IS, HDR
• Creative Filters
  Not supported
• Picture Styles
  Auto, Standard, Portrait, Landscape, Fine Detail, Neutral, Faithful, Monochrome, User Defined (x3)
• Colour Space
  sRGB, BT.709, BT.2020, Cinema Gamut
• Image Processing
  Brightness adjustment: ±1-stops in 1/3 stop increments
  White balance: Ambience Priorite and White priority are selectable
  Picture Style: Fine Detail is selectable, Fineness and Threshold of Sharpness are selectable.
  Clarity: Supported
  Auto Lighting Optimizer: Supported
  High ISO speed noise reduction: Supported
  Image Quality: Supported
  Lens Aberration Correction: Peripheral illumination correction, Distortion correction, Digital Lens Optimizer, Chromatic Aberration correction, Diffraction correction
• Drive Modes
  Single, Continuous High+, Continuous High, Continuous Low, Self-timer (2s+remote, 10s+remote, continuous)
• Continuous Shooting
  Max. Approx. 40 FPS with electronic shutter speed maintained for 330 JPEG (Cfexpress or SD Card ) and 150/140 RAW images (CFexpress/SD Card)⁷ .
  Pre-Continuous shooting is possible from 20 shots before the shutter button is fully pressed.⁸
• Intervalometer
  Supported
• Interval Timer
  Built in (Shooting interval: 1 sec.–99 hr. 59 min. 59 sec. Number of shots: 01–9999 or [unlimited])

File Type

• Still Image Type
  RAW 14 bit (12 bit A/D conversion)⁹ : RAW and C-RAW (Canon original RAW 3rd edition)
  JPEG 8 bit: 10 compression options
  HEIF 10 bit: 10 compression options
  Complies with Exif 3.00¹⁰ and Design rule for Camera File system 2.0
  Complies with Digital Print Order Format [DPOF] Version 1.1
• RAW+JPEG Simultaneous Recording
  Yes, any combination of RAW + JPEG or RAW + HEIF possible,
• Image Size
  RAW/ C-RAW:
  3:2 ratio 6960×4640, 1.6x (crop) 4320×2880
  JPEG/ HEIF:
  3:2 ratio (L, RAW, C-RAW) 6960×4640, (M) 4800×3200, (S1)3472×2320, (S2) 2400×1600
  1.6x (crop) (L) 4320×2880, (S2) 2400×1600
  4:3 ratio (L) 6160×4640, (M) 4256×3200, (S1) 3072×2320, (S2) 2112×1600
  16:9 ratio (L) 6960×3904, (M)4800×2688, (S1)3472×1952, (S2) 2400×1344
  1:1 ratio (L) 4640×4640, (M) 3200×3200, (S1) 2320×2320, (S2) 1600×1600
• Folders
  New folders can be manually created, named and selected
  Movie folder structure is adopting the XF-HEVC S / XF-AVC S format
• File Numbering
  (1) Consecutive numbering
  (2) Auto-reset
  (3) Manual reset
• File Naming
  Still:
  Preset code Unique 4-digit character string + 4-digit file number
  2 User Presets
  Movie:Adopting the XF-HEVC S / XF-AVC S formatCamera index, Reel number, Clip number, Codec type, Shooting start date, Shooting start time, Random ID, User defined 5 characters, Stream number, (Proxy)

EOS Movie

• Movie Type
  RAW Video: 7K (17:9) / (Open Gate 3:2)¹¹
  MP4 Video: 7K (Open Gate 3:2) / 1920 x 1280 (Open Gate 3:2, proxy) / 4K DCI (17:9) / 4K UHD (16:9) / 2K DCI (17:9) / Full HD (16:9)
• Movie Size
  RAW (Standard) (17:9) 6960 x 3672 (29.97, 25, 24, 23.98 fps)¹²
  RAW (Light) (17:9) 6960 x 3672 (59.94, 50, 29.97, 25, 24, 23.98 fps)¹³
  Open Gate RAW (Standard/ Light) (3:2) 6960 x 4640 (29.97, 25, 24, 23.98 fps)¹⁴
  Open Gate MP4 (3:2) 6912x 4608 (29.97, 25, 24, 23.98 fps) 3 type of intra or Long GOP
  4K DCI (17:9) 4096 x 2160 (119.9, 100, 59.94, 50, 29.97, 25, 24, 23.98 fps) 3 type of intra or Long GOP
  4K UHD (16:9) 3840 x 2160 (119.9, 100, 59.94, 50, 29.97, 25, 23.98 fps) 3 type of intra or Long GOP
  2K DCI (17:9) 2048 x 1080 (179.8, 150, 119.9, 100, 59.94, 50, 29.97, 25, 24, 23.98 fps) Intra frame or Long GOP
  Full HD (16:9) 1920 x 1080 (179.8, 150, 119.9, 100, 59.94, 50, 29.97, 25, 23.98 fps) Intra frame or Long GOP
  HDR movie recording at up to 59.94p in Normal modes of 4K DCI/UHD, 2K DCI/UHD, Full HD
  HDR movie recording at up to 29.97p in Fine modes of 4K DCI/UHD, 2K DCI/UHD, Full HD
• Colour Sampling (Internal Recording)
  RAW (Standard / Light)
  XF-HEVC S YCC422 10 bit¹⁵ H.265 / HEVC YCbCr 4:2:2 10 bits MP4
  XF-HEVC S YCC420 10 bit H.265 / HEVC YCbCr 4:2:0 10 bits MP4
  XF-AVC S YCC422 10bit¹⁶ H.264 / MPEG-4 AVC YCbCr 4:2:2 10 bits MP4
  XF-AVC S YCC420 8 bit H.264 / MPEG-4 AVC YCbCr 4:2:0 8 bits MP4
• Canon Log
  Custom Picture:
  C1: Canon 709
  C2: Canon Log 2
  C3: Canon Log 3
  C4: PQ
  C5: HLG
  C6: BT.709 Standard
  C7 – C20: User Defined
  11 Picture Styles
  14 Color Filters
• Movie Length
  Max. duration 6 hours for less than 100.0 fps movies. (100.0 fps or more max. duration 2 hours.)¹⁷ No 4 GB file limit with exFAT formatted SD cards. Maximum file size is unlimited using Cfexpress cards.
• High Frame Rate Movie
  4K – DCI 4096×2160 / UHD 3840×2160 at 119.9 / 100 fps – XF-HEVC 10 bit / XF-AVC 10 / 8 bit
  2K / Full HD – 2048×2160 / 1920×1080 at 179.8 / 150 / 119.9 / 100 fps- XF-HEVC 10 bit / XF-AVC 10 / 8 bit¹⁸
  Slow & Fast Motion Movie (S&F) mode – 180fps – 1fps playback speed
• Frame Grab
  8.8-megapixel JPEG still image frame grab from 4K DCI movie possible¹⁹
  8.3-megapixel JPEG still image frame grab from 4K UHD movie possible²⁰
  (HEIF only possible when HDR PQ is set)
• Bitrate / Mbps
  Note: Mainly PAL frame rates listed here, including some NTSC frame rates.²¹
  CRM:
  7K RAW Standard (29.97p): Approx. 2600 Mbps
  7K RAW Standard (25.00p): Approx. 2240 Mbps
  7K RAW Standard (24.00p/23.98p): Approx. 2150 Mbps
  7K RAW Light (59.94p): Approx. 2410 Mbps
  7K RAW Light (50.00p): Approx. 2010 Mbps
  7K RAW Light (29.97p): Approx. 1210 Mbps
  7K RAW Light (25p): Approx. 1010 Mbps
  7K RAW Light (24.00p/23.98p): Approx. 970 Mbps
  MP4 4K DCI fine/UHD Fine (oversampled):
  XF-HEVC S YCC422 10bit
  Standard LGOP(59.94p/50.00p): Approx. 225 Mbps
  Standard LGOP(29.97p/25.00p/24.00p/23.98p): Approx. 135 Mbps
  XF-HEVC S YCC420 10bit
  Standard LGOP(59.94p/50.00p): Approx. 150 Mbps
  Standard LGOP(29.97p/25.00p/24.00p/23.98p): Approx. 100 Mbps
  XF-AVC S YCC422 10bit
  High Quality Intra (59.94p/50.00p): Approx. 1200 / 1000 Mbps
  High Quality Intra (29.97p/25.00p/24.00p/23.98p): Approx. 600-480 Mbps
  Standard Intra (59.94p/50.00p): Approx. 900 / 750 Mbps
  Standard Intra (29.97p/25.00p/24.00p/23.98p): Approx. 450-360 Mbps
  Light Intra (59.94p/50.00p): Approx. 600 / 500 Mbps
  Light Intra (29.97p/25.00p/24.00p/23.98p): Approx.300-240 Mbps
  Standard Intra (59.94p/50.00p): Approx. 250 Mbps
  Standard LGOP 29.97p/25.00p/24.00p/23.98p: Approx. 150 Mbps
  MP4 4K DCI/UHD Normal (Not oversampled):
  XF-HEVC S YCC422 10bit
  Standard LGOP(119.9p/100.00p): Approx. 450 Mbps
  Standard LGOP(59.94p/50.00p): Approx. 225 Mbps
  Standard LGOP(29.97p/25.00p/24.00p/23.98p): Approx. 135 Mbps
  XF-HEVC S YCC420 10bit / XF-AVC SYCC420 8 bit
  Standard LGOP(119.9p/100.00p): Approx. 300 Mbps
  Standard LGOP(59.94p/50.00p): Approx. 150 Mbps
  Standard LGOP(29.97p/25.00p/24.00p/23.98p): Approx. 100 Mbps
  XF-AVC S YCC422 10bit
  High Quality Intra (59.94p/50.00p): Approx. 1200 / 1000 Mbps
  High Quality Intra (29.97p/25.00p/24.00p/23.98p): Approx. 600-480 Mbps
  Standard Intra (119.9p/100.00p): Approx. 1800 / 1500 Mbps
  Standard Intra (59.94p/50.00p): Approx. 900 / 750 Mbps
  Standard Intra (29.97p/25.00p/24.00p/23.98p): Approx. 450-360 Mbps
  Light Intra (119.9p/100.00p): Approx. 1200 / 1000 Mbps
  Light Intra (59.94p/50.00p): Approx. 600 / 500 Mbps
  Light Intra (29.97p/25.00p/24.00p/23.98p): Approx.300-240 Mbps
  Standard Intra (119.9p /100.00p): Approx. 500 Mbps
  Standard Intra (59.94p/50.00p): Approx. 250 Mbps
  Standard LGOP 29.97p/25.00p/24.00p/23.98p: Approx. 150 Mbps
  MP4 2K DCI / FullHD:
  XF-HEVC S YCC422 10bit Standard LGOP
  179.8p/150p: Approx. 150 Mbps
  119.9p/100p: Approx. 100 Mbps
  59.94p/50.00p/29.97p/25.00p/24.00p/23.98p: Approx. 50 Mbps
  XF-HEVC S/ XF-AVC S YCC420 10bit / 8bit Standard LGOP
  179.8p/150p: Approx. 105 Mbps
  119.9p/100p: Approx. 70 Mbps
  59.94p/50.00p/29.97p/25.00p/24.00p/23.98p: Approx. 35 Mbps
  XF-AVC S YCC422 10bit
  Standard Intra 179.8p/150p: Approx. 900 / 750 Mbps
  Standard Intra 119.9p/100p: Approx. 600 / 500 Mbps
  Standard Intra 59.94p/50.00p: Approx. 300 / 250 Mbps
  Standard Intra 25.00p/24.00p/23.98p: Approx. 150-120 Mbps
  Standard LGOP 179.8p/ 150p: Approx. 150 Mbps
  Standard LGOP 119.9p/100p: Approx. 100 Mbps
  Standard LGOP 59.94p/50.00p / 25.00p/24.00p/23.98p: Approx. 50 Mbps
  MP4 2K DCI/UHD (Proxy):
  XF-HEVC S / XF-AVC S YCC420 10bit / 8bit
  Standard LGOP 59.94p/50.00p/25.00p/24.00p/23.98p: Approx. 16 Mbps
  Light LGOP 59.94p/50.00p/25.00p/24.00p/23.98p: Approx. 9 Mbps
  Sub Movies 4K DCI ( oversampled )
  XF-HEVC S YCC422 10bit
  Standard LGOP(59.94p/50.00p): Approx. 225 Mbps
  Standard LGOP(29.97p/25.00p/24.00p/23.98p): Approx. 135 Mbps
  XF-HEVC S YCC420 10bit
  Standard LGOP(59.94p/50.00p): Approx. 150 Mbps
  Standard LGOP(29.97p/25.00p/24.00p/23.98p): Approx. 100 Mbps
  XF-AVC S YCC422 10bit
  Light Intra (59.94p /50.00p): Approx. 600 / 500 Mbps
  Light Intra (29.97p/25.00p/24.00p/23.98p): Approx.300-240 Mbps
  Standard LGOP (59.94p/50.00p): Approx. 250 Mbps
  Standard LGOP (29.97p/25.00p/24.00p/23.98p): Approx. 150 Mbps
  XF-AVC S YCC420 8bit
  Standard LGOP (59.94p/50.00p): Approx. 150 Mbps
  Standard LGOP (29.97p/25.00p/24.00p/23.98p): Approx. 100 Mbps
• Dual Card Recording
  Yes, record to both cards, relay, Proxy or sub movie
• Microphone
  – Built-in stereo microphone (48 Khz, 24 / 16-bit x 2 channels)
  – External microphone via the 3.5 mm stereo mini jack (3-pin) terminal
  – Digital external microphone via Multi-Function shoe
  4CH audio support (Multi-Function shoe takes priority and can be combined with either the External microphone or the built in microphone)²²
• HDMI Display
  3 different Display during HDMI connection²³ :
  – Output to external monitor only (output of images and shooting information, images are recorded to the card)
  – Camera screen and External Monitor output (Simultaneous recording to camera and external recorder, camera screen shows images with shooting information)
  – Camera screen and External Monitor output (Simultaneous recording to camera and external recorder, HDMI Display shows images with shooting information)
• HDMI Output
  7K RAW (Standard) ProRes recording via HDMI²⁴
  4K (DCI) 59.94p/50p/29.97p/25p/24p/23.98p,
  4K (UHD) 59.94p/50p/29.97p/25p/23.98p,
  Full HD 59.94p/60i/59.94i/50p/50i/24p,
  480p 59.94p
  576p 50p
  Uncompressed YCbCr 4:2:2, 10-bit, sound output via HDMI is also possible
  HDMI streaming is also possible²⁵
• Focusing
  Dual Pixel CMOS AF II with Eye/Face Detection and Tracking AF (people, animals and vehicles) , Movie Servo AF, Manual Focus
• ISO
  Auto: 100-25600, H: up to 102400 (when custom picture is off)
  Manual: 100-25600, H: up to 102400 (when custom picture is off)

Other Features

• Network Options
  Communication functions:
  – Via Wi-Fi: FTP, FTPS, EOS Utility, image.canon, Camera Connect, Streaming services, Content Transfer Professional, Camera Control API
  – Via Bluetooth: Camera Connect, BR-E1
  – Via USB: EOS Utility, Camera Connect, Content Transfer Professional, Video calls/streaming (UVC/UAC) 4k 60p, 4k 30p, Full HD 60p and Full HD 30p
  Simultaneous use of communication functions:
  – FTP (wireless LAN) + EOS Utility (USB)
• Metadata Tag
  User copyright information (can be set in camera)
  Image rating (0-5 stars)
  IPTC data (registered with EOS Utility)
  IPTC data (via CTP app)
  IPTC IIM (via CTP app)
  NewsML-G2 (News Metadata) (via CTP app)
  Image transfer with caption (Caption registered with EOS Utility)
• LCD Panel / Illumination
  N/A
• Water/Dust Resistance
  Yes²⁶
• Voice Memo
  No
• Intelligent Orientation Sensor
  Yes
• Playback Zoom
  1.5x – 10x in 15 steps
• Display Formats
  (1) Single image
  (2) Single image with information (2 levels)
  Basic – Shooting information (shutter speed, aperture, ISO and Image quality)
  Detailed – Shooting information (shutter speed, aperture, ISO, metering Image, quality and file size), Lens information,
  Brightness and RGB histogram, Waveform monitor(movie mode only), White balance, Picture Style, Colour space and noise reduction, Lens optical correction, GPS information, IPTC information
  (3) 4 image index
  (4) 9 image index
  (5) 36 image index
  (6) 100 image index
  (7) Jump Display (1, 10 or specified no. 1-100 images, start of burst sequence Date, Folder, Movies, Stills, Protected images, Rating)
  (8) Movie edit
  (9) RAW processing
  (10) Rating
• SlideShow
  Image selection: All images, by Date, by Folder, Movies, Stills, Protected images or Rating
  Playback time: 1/2/3/5/10 or 20 seconds
  Repeat: On/Off
• Histogram
  Brightness / RGB
• Highlight Alert
  Yes
• Image Erase
  Select and erase images / Select range / All images in folder / All images on card / All found images (only during image search)
• Image Erase Protection
  Erase protection of Select images / Select range / All images in folder / Unprotect all images in folder / All images on card / Unprotect all images on card / All found images / Unprotect all found images (only during image search)
• Self Timer
  2 or 10 sec. Continous.
• Menu Categories
  (1) Shooting menu
  (2) AF Menu
  (3) Playback menu
  (4) Communication Function (Network)
  (5) Function settings (Setup menu)
  (6) Customize controls
  (7) Custom Functions menu
  (8) My Menu
• Menu Languages
  29 Languages English, German, French, Dutch, Danish, Portuguese, Finnish, Italian, Norwegian, Swedish, Spanish, Greek, Russian, Polish, Czech, Hungarian, Vietnamese, Hindi, Romanian, Ukrainian, Turkish, Arabic, Thai, Simplified Chinese, Traditional Chinese, Korean, Malay, Indonesia and Japanese
• Firmware Update
  Update possible by the user using Camera Connect app or EOS Utility (Camera, Lens, External Speedlite, BLE remote control, Lens adapter, Power zoom adapter, multi-function shoe compatible accessories)

Interface

• Computer
  SuperSpeed Plus USB 3.2 Gen 2 USB Type-C® connector
• Wi-Fi
  Wireless LAN (IEEE 802.11ac) (5 GHz / 2.4 GHz)²⁷ , with Bluetooth 5.1 support
• Other
  HDMI Full size (Type A), External Microphone In (Stereo mini jack), Headphone socket (Stereo mini jack), E3-type terminal (remote control terminal), Multi-Function shoe

Direct Print

• Canon Printers
  Not supported
• PictBridge
  Not supported

Storage

• Type
  1x CFexpress type B maximum capacity 8TB (compatible with CFexpress 2.0 and VPG400)
  1x SD/SDHC/SDXC and UHS-II

Supported Operating System

• PC
  Windows 11
• Macintosh
  macOS 15, macOS 14, macOS 13

Software

• Image Processing
  Digital Photo Professional Ver. 4.21.10 or later
  Digital Photo Professional Express mobile app Ver. 1.12.10 or later.
• Other
  EOS Utility Ver. 3.20.10 or later, Picture Style Editor Ver. 1.32.10 or later, EOS Lens Registration Tool, EOS Web Service Registration Tool, Canon Camera Connect app Ver. 3.5.11 or later (iOS/Android), Content Transfer Professional app (iOS/Android).

Power Source

• Batteries
  Rechargeable Li-ion Battery LP-E6P (supplied)²⁸
• Battery Life
  With LCD Approx. 640 shots (at 23°C)²⁹
• Battery Indicator
  6 levels
• Power Saving
  – Screen dimmer: 5 sec. / 10 sec. / 15 sec. / 20 sec. / 25 sec. / 30 sec. / Disable
  – Screen off: 5 sec. / 15 sec. / 30 sec. / 1 min. / 3 min. / 5 min. / 10 min. / 30 min. / Disable
  – Auto power off: 15 sec. / 30 sec. / 1 min. / 3 min. / 5 min. / 10 min. / 30 min. / Disable
  – Viewfinder off: 1 min. / 3 min. / Disable
• Power Supply & Battery Chargers
  USB Power Adapter PD-E1, USB Power Adapter PD-E2, DC Coupler DR-E6P³⁰ , Battery Charger LC-E6E, Car Battery Charger CBC-E6

Accessories

• Wireless File Transmitter
  N/A
• Cases / Straps
  Hand Strap E2, Protecting Cloth PC-E2, Protecting Cloth PC-E1, Rain Cover ERC-R5 L, Rain cover ERC-R5 S
• Lenses
  RF and RF-S lenses (EF & EF-S via Lens adapters)³¹
• Lens Adapters
  EF TO EOS R ADAPTER, EF TO EOS R ADAPTER WITH CONTROL RING, EF TO EOS R Drop in filter ADAPTER
• Flash
  N/A
• Battery Grip
  Not supported
• Remote Controller / Switch
  Wireless Remote Controller BR-E2, Wireless Remote Controller BR-E1, Remote Switch RS-60E3, Remote Switch RS-80E3, Timer Remote Controller TC-80N3 (with RA-E3)
• Other
  Directional Stereo Microphone DM-E1D, Stereo Microphone DM-E100, Directional Microphone DM-E1, Interface Cable IFC-400U, Interface Cable IFC-100U, Off Camera Shoe Cord OC-E4A, Camera Shoe Cover ER-SC2, Smartphone Link Adapter AD-P1, Multi-Function Shoe Adapter AD-E1, Tripod Grip HG-100TBR³² , Tripod Grip HG-200 TBR³³ , GPS Receiver GP-E2³⁴

Physical Specifications

• Body Materials
  Magnesium Alloy body and Chassis with some components consisting of polycarbonate with glass fibre
• Operating Environment
  0 – 40 °C, 85% or less humidity
• Dimensions (W x H x D)
  Approx. 141.8×83.3×79.7 mm
• Weight (Body Only)
  Approx. 598 g (688g with CFexpress card and battery)
